high frequency welded(HFW) steel pipe
- group name
- round steel pipe
- Min Order
- 5 ton
- brand name
- Yuantai Derun Steel Pipe Manufacturing Group
- model
- hfw steel pipe
- Nearest port for product export
- XINGANG PORT TIANJIN CHINA, TANGSHAN CHINA, SHANGHAI CHINA, DALIAN PORT
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, Cash
- update time
- Wed, 04 Dec 2024 00:39:56 GMT
Paramtents
Thickness 0.5- 16 mm
Supply capacity Annual output of 5 million tons
Certification CE,LEED,BV,PHD&EPD,BC1,EN10210/10219,ISO
Tolerance as required
Length 0.5-26.5M according to client requirement
Standards ASTM A500/A501,EN10219/10210,JIS G3466
Materials Gr.A,Gr.B,Gr.C,S275J0H,S355JR,S355J0H,S355J2H,A36,
Packaging Customers't Requirement
Delivery Time 7-30 Days
Packging & Delivery
-
Min Order5 ton
Briefing
high frequency welded(HFW) steel pipe China factory yuantaiderun(oem odm obm),low cost,high quality,complete sizes.
Detailed
High Frequency Welded(HFW) Steel Pipe
High Frequency Welded(HFW) Steel Pipes are robust, cost-effective solutions for a range of industrial applications, manufactured through a welding process that joins steel plates using high-frequency currents.
HFW Steel Pipe Shape
At Yuantai Derun,we can produce round HFW steel pipes,HFW square pipes and HFW rectangular pipes. Now tell me which shape you need?
Round HFW Pipe
HFW Square Pipe
HFW Rectangular Pipe
Complete HFW Steel Pipe Sizes For You
At Yuantai Derun, HFW steel pipe size specifications are more complete, square HFW pipe caliber range is: 10*10-500*500mm, round HFW pipe caliber range is: 10.3-609mm, rectangular HFW pipe caliber range is: 10*15-400*600mm, wall thickness range: 0.5-16mm, length range is 0.5-26.5 meters and accept customization. The length range is 0.5-26.5 meters and accepts customization. Customized options include caliber, wall thickness, length and so on. Send us your size request now!
|
Shape
|
OD(mm)
|
WT(mm)
|
Length(M)
|
|
square
|
10*10-500*500
|
0.5-16
|
0.5-26.5
|
|
round
|
103-609
|
0.5-16
|
0.5-24
|
|
rectangular
|
10*15-400*600
|
0.5-16
|
0.5-26.5
|
Coating
At Yuantai Derun, In order to better protect your HFW steel pipe from external corrosion and rust, we can hot dip galvanizing, painting or oiling the black HFW steel pipe. For details, please consult your account manager.
HFW Pipe Manufacturing Process
At Yuantai Derun,HFW steel pipe manufacturing process has mainly several step below:
Uncoiling Of Steel Coils
Straightening
High Altitude Feeding - HFW
Roll Cold Molding To Square Round Or Rectangular Shape
High Frequency Welding
Cut To Stock
Benifit
High-frequency welded steel pipe produced by Yuantai Delun has the following advantages:
1. high strength
The advanced high frequency welding process makes the welded seam of the steel pipe more compact, higher strength, stronger and more durable.
2. High precision
The whole process adopts electric control automation, which makes the size precision of high-frequency welded steel pipe higher and the error smaller.
3. High quality
Each high-frequency welded steel pipe goes through several processing procedures and inspection procedures after it comes off the line, not only the appearance is neat and clean, the mouth is burr-free, but also the products can be made traceable.
Application And Projects
Construction field: High frequency welded steel pipe is widely used in construction field for scaffolding, bridges, tunnels, highways and other projects, its excellent performance characteristics to ensure the safety and stability of the project.
Petrochemical field: High frequency welded steel pipe is used to transport oil, gas, water and other media in petrochemical field, its good corrosion resistance and sealing performance to ensure the long-term stable operation of the pipeline.
Mechanical manufacturing: High frequency welded steel pipe is used to manufacture various mechanical parts and structural parts in the field of mechanical manufacturing, such as bearing seats, brackets, drive shafts and so on.
Other fields: High-frequency welded steel pipe is also widely used in automobile, shipbuilding, electric power, communication and other fields, and its excellent performance characteristics provide strong support for the development of these fields.
FAQ
How To Get hfw square pipe quotes?
You can cantact sales of Yuantai Derun,or contact the local metal supermarket.
Is Yuantai Derun the largest china hfw square pipe manufacturer?
Yes,Among the many Hfw Rectangular Pipe Factories, Yuantai Derun is the largest HFW square pipe and HFW rectangular pipe manufacturer in China.
what is hFW meaning?
Hfw means high frequency welded.
